Many developers treat OCPP (Open Charge Point Protocol) as a black box. You send a JSON object, magic happens, and a car charges. But to build resilient systems, you need to understand what's happening under the hood.

This guide peels back the layers of abstraction to show you the raw protocol.

1. The Transport Layer: WebSockets & Subprotocols

OCPP runs over WebSockets (WSS). The handshake is critical. When a charger connects to your server, it MUST include the Sec-WebSocket-Protocol header to negotiate the version.

ocpp1.6 -> For OCPP 1.6J
ocpp2.0.1 -> For OCPP 2.0.1

If your server doesn't return this header in the upgrade response, the charger will immediately disconnect.

Example Request Headers:

GET /webServices/ocpp/CP001 HTTP/1.1
Host: csms.example.com
Upgrade: websocket
Connection: Upgrade
Sec-WebSocket-Key: dGhlIHNhbXBsZSBub25jZQ==
Sec-WebSocket-Protocol: ocpp1.6, ocpp1.5
Authorization: Basic dGVzdDp0ZXN0

Example Response:

HTTP/1.1 101 Switching Protocols
Upgrade: websocket
Connection: Upgrade
Sec-WebSocket-Protocol: ocpp1.6

2. Message Framing (RPC)

OCPP-J isn't just "sending JSON". It follows a strict array-based RPC format. Every message is a JSON Array containing 3 or 4 elements.

The Message Type ID

The first element is always an integer ID defining the message type:

2: CALL (Request)
3: CALLRESULT (Response)
4: CALLERROR (Error)

TYPE 2: CALL (Request)

Format: [2, "MessageId", "Action", { payload }]

MessageId: Unique string (UUID) to correlate the response.
Action: The name of the operation (e.g., BootNotification).
Payload: The data object.

[
  2,
  "19223201",
  "BootNotification",
  {
    "chargePointVendor": "VendorX",
    "chargePointModel": "ModelY"
  }
]

TYPE 3: CALLRESULT (Response)

Format: [3, "MessageId", { payload }]

MessageId: Must match the ID from the CALL.

[
  3,
  "19223201",
  {
    "status": "Accepted",
    "interval": 300,
    "currentTime": "2024-05-28T10:00:00Z"
  }
]

TYPE 4: CALLERROR (Error)

Format: [4, "MessageId", "ErrorCode", "Description", { details }]

Used when the request cannot be processed (e.g., validation failed, internal error).

[4, "19223201", "NotSupported", "Action not found", {}]

3. Important State Machines

OCPP is stateful. You cannot just send any command at any time.

The Connector Status

Each connector on a charger has a status.

Available: Ready to use.
Preparing: EV plugged in, but not authorized yet.
Charging: Contactors closed, energy flowing.
SuspendedEV / SuspendedEVSE: Paused (by car or by charger).
Finishing: Session ended, unplugging...
Faulted: Something went wrong.

Transitioning from Available -> Charging usually requires the StartTransaction flow. If a charger sends StartTransaction while it's already Charging, you have a "ghost session" or a state desync.

4. Security Profiles Explained

Security is a major focus in modern OCPP.

Profile 1: Basic Auth + No Encryption

URL: ws://csms.com/ocpp/CP001
Auth: HTTP Basic (Authorization header).
Risk: Passwords sent in cleartext. Do not use in production.

Profile 2: Basic Auth + TLS

URL: wss://csms.com/ocpp/CP001
Auth: HTTP Basic.
Encryption: TLS 1.2 or 1.3.
Trust: The Charger validates the Server's certificate.
Use Case: Standard for most public chargers today.

Profile 3: Mutual TLS (mTLS)

URL: wss://csms.com/ocpp/CP001
Auth: Client Certificate.
Mechanism: The server validates the Charger's certificate. No passwords are used.
Complexity: High. You need a PKI (Public Key Infrastructure) to issue and rotate certificates for every charger.

5. Smart Charging (The Complex Part)

OCPP allows you to control the charging power dynamically. This is done via Charging Profiles.

A profile consists of a ChargingSchedule with ChargingSchedulePeriods.

{
  "connectorId": 1,
  "csChargingProfiles": {
    "chargingProfileId": 1,
    "stackLevel": 1,
    "chargingProfilePurpose": "TxProfile",
    "chargingProfileKind": "Absolute",
    "chargingSchedule": {
      "chargingRateUnit": "A",
      "chargingSchedulePeriod": [
        { "startPeriod": 0, "limit": 32.0 }, // Start at 32A
        { "startPeriod": 1800, "limit": 16.0 }, // Drop to 16A after 30 mins
        { "startPeriod": 3600, "limit": 0.0 } // Stop after 1 hour
      ]
    }
  }
}

Stack Level: Profiles have priority. A profile with Stack Level 2 overrides Level 1. This lets you layer logic:

Level 0: Hardware Limit (never exceed 32A).
Level 1: Site Limit (don't blow the building fuse).
Level 2: User Limit (user successfully requested eco-mode).

Conclusion

OCPP is more than just API calls; it's a protocol designed for physical hardware safety and reliability. By understanding the framing, state machines, and security profiles, you can build systems that aren't just "compliant", but robust enough for the real world.
